Equipment

Horizontal Machining Centers - Twenty-Three (23) Machines

  • cnc equipment mennie machine companySeven (18)Daewoo DHP 400 or 4000 HMC - X=22, Y=22, Z=19.7
  • One (1) Daewoo DHP 500 HMC - X=31.49, Y=27.56, Z=29.52
  • Six (6)Daewoo DHP 630 – 50 Taper - X=39.37, Y=33.46, Z=33.46
  • One (1)Mori Seiki NH4000d - X=22, Y=22, Z=19.7
  • Eight (8)Makino A51 - X=22, Y=22, Z=19.7



CNC Vertical Machine Centers – Forty-Nine (49) Machines

  • One (1) HAAS Mini – Mill - X=16, Y=20, Z=10
  • Thirteen (13) HAAS VF – 1 VMC - X=20, Y=16, Z=20
  • Seven (7) HAAS VF-2 VMC - X=30, Y=16, Z=20
  • Thirteen (13) HAAS VG-3B - X=40, Y=20, Z=25
  • One (1) HAAS VG-4 VMC - X=50, Y=20, Z=25
  • One (1) Mori Seiki - X=40.15, Y=20.07, Z=24.6
  • One (1) Daewoo DMV – 4020 VMC 40 Taper - X=40.15, Y=20.07, Z=24.6
  • Nine (9) Daewoo DMV – 4020 VMC 50 Taper - X=40.15, Y=20.07, Z=24.6

CNC Horizontal Lathes – Thirty-One (31) Machines

  • Two (2) Daewoo PUMA 6S Lathes - 6” chuck / 12 station turret/max turn dia 14.2,  X travel – 7.9 – Z travel -15
  • Two (2) Daewoo PUMA 230C Lathes - 12” chuck / 10 station / max turn 13.8 / Length – 21.1, X travel – 9.5 Z travel – 22.8
  • Four (4) Daewoo PUMA 240B - 8” chuck / 12 station/max turn 13.7 / Length - 17.21, X travel – 9.5 – Z travel – 22.8
  • Two (2) Daewoo PUMA 240C Lathes - 10” chuck / 10 station / max turn 13.8 / Length 17.21, X travel – 9.5 Z travel – 22.8
  • Two (2) Daewoo PUMA 240-GL - 8” chuck / 12 station turret / working dia 8.27, X travel – 9.5 Z travel 22.8
  • Six (6) Daewoo PUMA 240LC - 10” chuck / 12 station/max turning dia 13.8, X travel – 9.5 Z travel – 26.8
  • Two (2) Daewoo PUMA 8HC Lathes - 8” chuck / 12 station turret/max turning dia 14.6, X travel – 8.3 Z travel – 21.7
  • Six (6) Daewoo PUMA 250B Lathes - 12” chuck / 10 station/max turning 15.7 / Length 25.0, X travel – 11.1 Z travel - 26.8
  • Three (3) Daewoo PUMA 300C Lathes - 15” chuck / 12 station/max turning dia 15.7, X travel – 11.1 Z travel  - 26.8
  • One (1) Daewoo PUMA 350 Lathe - 18” chuck / 10 station turret / max turn 21.7, X travel – 14.3 Z travel – 43.5
  • One (1) Daewoo PUMA 12LB Lathe - 18” chuck / 10 station turret / max turn 19, X travel – 10.2 Z travel – 41.3
  • One (1) Daewoo PUMA 12LC Lathe - 18” chuck / 12 station turret / max turn 19, X travel – 10.2 Z travel – 41.3
  • One (1) Daewoo PUMA 15 Lathe - 18” chuck / 12 station turret / max turn 19, X travel – 10.2 Z travel – 41.3

CNC Vertical Lathes – Forty-Three (43) Machines

  • Ten (10) Daewoo PUMA V10 Vertical Lathes - 10” chuck / 8 station turret / 16.14 max dia., X travel – 15.7 Z travel – 13
  • Seven (7) Daewoo PUMA V300G Vertical Lathes  - 10” chuck / 16.14 max dia., X travel – 15.7 Z travel – 13.0
  • Seven (7) Daewoo PUMA V300 Vertical Lathes - 10” chuck / 8 station turret / 16.14 max dia., X travel – 15.7 Z travel 13.0
  • Four (4) Daewoo PUMA V550 – 2SP Lathes - 18” chuck / 10 station turret / max turn dia. 26.7, X travel – 13.78 Z travel – 26.7
  • Two (2) Doosan V740 Lathes - 18” chuck / 12 station / max turn dia. 29.13 / Length 29.92, X travel – 14.96 Z travel – 29.92
  • Eight (8) EMAG VSC 400 Lathes - 15.75” Chuck / 12 station turret / 16.53 swing dia., X travel – 33.46 Y travel – 12.4 Z travel – 12.4
  • Four (4) EMAG VSC 01/315 - 15.75” chuck / 12 station turret / 16.53 swing dia., X travel – 33.46 Y travel – 12.4 Z travel – 12.4
  • One (1) LM – 21 Lathe - 8” chuck / 8 station / max turn dia. 4.68 / Length 4.31, X travel – 6.31 Z travel – 10.25

Fourteen (14) CNC FANUC Robots

careers at mennie machine company·   Fourteen (14) LR-MATE FANUC Robots of Various Sizes

Nine (9) CNC Gun Drilling Machines

  • Eldorado 6 – spindle Gun Drill Machine (2)
  • Dual Head Injection Drill Machine
  • EMAG Drill Machine
  • EMAG Drill Machine
  • Dehoff Gun Drill (2)
  • Eldorado Gun Drill Machine (2)

 CNC Grinders (9)

  •  Oerlikon / Mattison 24x42x24 Grinder
  • OD 6IMDE Mitsubishi Grinder
  • RC32 Mitsubishi Grinder
  • GE4P – 50 Toyoda Grinder
  • Mitsubishi Grinder
  • Okamoto Grinder

 Spline Rollers(2)

  • West Michigan Spline Roller
  • West Michigan Spline Roller

Heat Treatment Machines (4)

  • Pillar 200KW Heat Treat
  • Pillar 200KW Heat Treat
  • Pillar 150KW Heat Treat
  • FECO Temper Oven

Honing Machines

  • Finite Hone
  • Accu-Cut Hone

Misc Miscellaneous

  • Ten (10) Parts Washers
  • Four (4) Balancers
  • Eight (8) Broaches
  • Four (4) Face and Center
  • Two (2) Mills
  • One (1)Polishing Machine
  • One (1) HEALD Horizontal Boring Machine
  • One (1) Falcon  / Chevalier
  • (1)Part Stamping Machine
  • One (1) Peter Wolters Lap Machine
  • One (1) EnerPac 25 / 50 Ton Press
  • One (1) Surftran Thermal Deburr Machine with de-oxidation

Quality Control Lab Equipment

  • One (1) CNC Mitutoyo BHN 706 - X=24.5, Y=22.5, Z=16
  • One (1) CNC Mitutoyo Bright Apex 1220 - X=44, Y=77, Z=36
  • One (1) CNC Mitutoyo BHN 1010L  - X=39.37, Y=39.37, Z=23.62
  • One (1) CNC Mitutoyo Strato 707 - X=26, Y=26, Z=22
  • One (1) Taylor Hobson Form Talysurf PGI 420 - X=120mm, Z=450mm
  • One (1) Mitutoyo Contracer CV-524 - X=100mm, Z=300mm
  • One (1) Mitutoyo Roundness Tester RA116 - Table Max Probing Diameter = 280mm
  • One (1) Mitutoyo Profilometer SJ-500 - X=50mm
  • One (1) Newage MT-91 Microhardness Tester
  • One (1) Optical Comparator
